SkyLink 5100 (Land IoT)
The SkyLink 5100 by Blue Sky Network delivers next-generation satellite connectivity to any location on the planet. This compact and versatile communications terminal is powered by the truly global Iridium® network, providing enterprise-grade voice, remote monitoring, and data connection.
As a certified Iridium Connected® product, the SkyLink 5100 is designed for complete business efficiency, safety and continuity coverage. Its slim design allows for easy mounting on fixed or mobile units to transfer real-time data from existing sensors, asset utilization and IoT/M2M monitoring tools. With speed 88Kbps, sensor or SCADA data transmission can be sent quickly in a large number of bytes.
In the field, this device is very flexible to be used as a portable communication tool and as a media sharing platform to update the latest information from workers in remote areas. WWith the SkyLink 5100, achieve total connectivity for all assets, in every location, across the globe.
SkyLink 5100 (Land IoT)
The SkyLink 5100 by Blue Sky Network delivers next-generation satellite connectivity to any location on the planet. This compact and versatile communications terminal is powered by the truly global Iridium® network, providing enterprise-grade voice, remote monitoring, and data connection.
As a certified Iridium Connected® product, the SkyLink 5100 is designed for complete business efficiency, safety and continuity coverage. Its slim design allows for easy mounting on fixed or mobile units to transfer real-time data from existing sensors, asset utilization and IoT/M2M monitoring tools. With speed 88Kbps, sensor or SCADA data transmission can be sent quickly in a large number of bytes.
In the field, this device is very flexible to be used as a portable communication tool and as a media sharing platform to update the latest information from workers in remote areas. WWith the SkyLink 5100, achieve total connectivity for all assets, in every location, across the globe.
SkyLink 5100 (Land IoT)
SkyLink 5100 (IoT Land) Technical Specification
| Mechanical | |
| Dimensions (Data Gateway) | 8.0 x 5.0 x 1.5 in (127 x 203 x 32 mm) |
| Dimensions (Communications Companion, optional) | 5 x 8.5 x 1.35 in (123 x 215 x 34 mm) |
| Weight (per unit) | 1.6 lb. (0.7 kg) |
| LED Behaviour | Green = Initial Power On |
| Red = Unit in Bootloader Mode | |
| Blue Blink = OS is Booting | |
| Blue Steady = Device is Ready | |
| Red Blink = Iridium Firmware Upgrade | |
| Blue Blink = SkyLink Firmware Upgrade | |
| Environmental | |
| Operating temperature range | -40°C to +70°C |
| Storage temperature range | -40°C to +85°C |
| Operating humidity range | ≤ 75% RH |
| Storage humidity range | ≤ 93% RH |
| Ingress Protection Rating | IP65 |
| Mounting options | Vertical, Horizontal, Remote Antenna |
| Electrical | |
| External power | 10 – 34 VDC |
| POE | |
| Power consumption | 7W nominal power |
| 18W peak power | |
| Interfaces | |
| Connectors | 1x cellular SMA female connector |
| 1x Iridium SMA female connector | |
| 2x M12 connectors (1x Ethernet & Power, 1x USB & RS232) | |
| Wi-Fi | 2.4 / 5 GHz |
| IEEE 802.11 ac / a / b / g / n | |
| GNSS Positioning | |
| Multi-constellation GNSS receiver in cellular module | GPS |
| GLONASS | |
| BeiDou | |
| Galileo | |
| Tracking Channels | 33 |
| acquisition channels | 99 |
| PRN channels | 210 |
| CEP horizontal position accuracy | < 2.5 m |
| Connectivity | |
| Iridium Certus® 100 | Simultaneous voice and IP data |
| 88 Kbps receive (DL) / 22 Kbps transmit (UL) | |
| Frequency: 1616 MHz – 1626.5 MHz | |
| Two (2) high-quality voice channels | |
| User-accessible SIM | |
| Cellular | LTE-A CAT 6 module with M.2 form factor |
| Supports LTE-A carrier aggregation | |
| Worldwide LTE-A and 3G UMTS / HSPA(+) coverage | |
| 300 Mbps receive (DL) / 50 Mbps transmit (UL) | |
| User-accessible SIM | |
- Iridium Certus® 100 Services
- Cellular LTE, 3G, 4G
- Internet Access
- Two (2) Iridium Voice Lines
- GNSS Positioning
- Wi-Fi and Bluetooth
- Least-cost Routing
- Local Dynamic Firewall
- Telemetry
- Remote monitoring
- Internet/VPN
- Push-to-Talk (PTT)
- Media sharing
- Asset utilization
- Graphical weather
- Kemampuan koneksi dual-mode (selular dan satelit)
- Didukung dengan panggilan suara, input/output sensor dan soket RJ45.
- Dapat menampilkan posisi aset karena sudah dilengkapi GNSS.
- Dual-Mode Data Gateway
- Helical Iridium-approved Antennas, specific for Iridium Certus Technology
- SkyLink Mounting Bracket
- Power Adapters
- Pigtail Ethernet Adapter
- Ethernet Cable
